1.5KG Mini Palm VET Diagnostic Ultrasound Equipment Portable
Ultrasound Scanner
Main Features:
Full digital beam forming technology
Generate Report
7 inch TFT LCD
A/DC and LI-battery operated
Human and veterinary double system(depend on your needs)
Light and compact design, simple to use
High quality keyboard and clear image
USB 2.0 for real-time picture uploading to PC
Probe automatic identification
Net weight: 1.2 Kgs
Dimension: 320×170×65mm
Main Technical Specification:
· Application: Cattle, Equine, Sheep, Dog, Cat,
· Scanning Method: Convex, Micro-convex, Linear, Rectal
· Frequency for Convex : 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0
· Display Mode: B, B+B, B+M, M, 4B
· Gray Scale: 256 levels
· Gamma: 4
· Monitor: 7 inch LCD
· Operation interface: English/Chinese switchable
· Scanning Deepth : 180mm
· Image magnification: *1.0, *1.2,*1.3 *1.5,*1.6, *1.8, *2.0 times
· Image control: left/right, black/white, up/down
· General Measurement: Distance, Circumference/Area, Volume, Heart
Rate
· 512 frames for cine-memory
· Human Body Mark : 5 kinds
· 4 focusing combination selectable
· Characteristic showing in real-time clock, ID, Sex, Age, Hospital
name, Focusing Info and Gain (Near, Far, Overall) info.
· 8 Segments of TGC adjustment, full gain control
· Puncture function is available under B mode.
· Generate HistoG
Veterinary Measurement:
Bovine: BPD , CRL
Equine :BPD, GSD
Ovine: BPD, CRL
Canine: CRL, BD
Feline: BD, HD
Standard configuration:
Main unit
Convex array probe
Li-battery
USB
Options:
Linear array probe
Micro-Convex array probe
Rectal probe
Video Printer
B ultrasonic diagnostic performance requirements file
| performance | Probe style and standard frequency |
| Standard frequency of probe | 3.5 MHz | 6.5MHz |
| Random error of frequency | Deviation of Sound frequency and standard frequency should ≤±15% |
| Probe | linear, R≥60mmconvex | linear(linear), R≥60mm convex | R＜60mm convex
|
| Investigation depth,mm | ≥180 | ≥70 | ≥60 |
| Axial resolution,mm | ≤2 (depth≤80) ≤3 (80＜depth≤130) | ≤1 (depth≤50) | ≤1 (depth≤40) |
| Lateral resolution,mm | ≤3 (depth≤80) ≤4 (80＜depth≤130) | ≤2 (depth≤40) | ≤2 (depth≤30) |
| Geometric position accuracy,% | crosswise≤10 Length wises≤5 | crosswise≤5 Length wises≤5 | crosswise≤10 Length wises≤5 |
| Dead zone,mm | ≤4 | ≤3 | ≤4 |
| Slice thickness,mm | ≤9 | ≤5 | ≤5 |
| Pupil error,% | ≤±20 | ≤±20 | ≤±20 |
| M mode time error,% | ≤5 | -- | -- |
| M mode distance error,% | ≤5 | -- | -- |
