25 MM USB Linear Probe 128 E Portable Ultrasound Scanner Color
Doppler 7.5 M
Description:
The most important types of Statemed USB probe is a machine
combined the international leading ultrasonic concept and modern
intelligent hardware technology to realize the point-of-care usage
of ultrasound, usually performed by ordinary doctors, surgeons,
anesthesiologist, nurses without special ultrasonic diagnositc
skills.
Product Features:
1. Point-of-care diagnostic tools
2. 128 elements probes, touch High level image
3. Light weight, easy operation
4. Remote support system to share, read images and videos
5. Wide application: Clinic, First Aid, Emergency, Patrol, Ward
Round, Bedside, ICU, Patients home, etc.
Application:
Abdomen / Obstetrics / Gynecology / Urology / Small Parts /
Vascular / Pediatrics / Musculoskeletal
Electrical Power:
Voltage: 5V
Maz Power: 0.25V
Physical Specifications:
Packing Size: 210mm×130mm×50mm
Packing Weight: 400g
Cine/Image Memory:
Cine Memory: 200 frame
Capture area: Image only / full screen
DICOM Connectivity:
DICOM3.0 Storage
Image Storage:
Storage Format: JPEG, MP4
Technology:
| Full field synthetic aperture imaging Tech |
| Multi-beam formation Tech |
| Speckle Reduction Tech |
| Phase-inverse Harmonic Imaging Tech |
| Duplex Synchronous Display |
| Directional Power Doppler |
| Imaging Parameters Preset |
General Performance:
Digital Beamformer Channels: 64 chanels
Beam-former Frequency Range: 1018 Mhz
Imaging Performance:
| Startup Time (Max) | Avg. < 10 seconds |
| Preset Switching Time | Avg. < 1 second |
| Storage Time (Image to Disk) | Avg. < 1 second |
Transducers:
| Probe | Convex Array Probe | Linear Array Probe |
| Frequency | Central 3.5 MHz (2.0MHZ to 5.0MHZ) | Central 7.5 MHz (5.0MHZ to 10.0MHZ) |
| Pitch | 0.78mm | 0. 5mm |
| Radius | 60mm | N/A |
| Elements | 80 | 80 |
User Interface: Full touch-screen-based operating principles
Imaging Modes: B, M, 2B, B/C, B/D, B/C/D
B-Mode:
| Maps | 8 |
| Gain | 0~100 |
| TGC | 6 Sliders |
| Dynamic Range | 45~80dB |
| Depth | Max. 24cm |
| Chroma | 0~7 |
| Grayscale Levels | 256 |
| Frame Rate | Max.15 Hz |
| Persistence/ Frame Average | 1~4 |
| Top/Bottom/Left/Right Reverse | Yes |
| Speckle Reduction | Yes |
| Harmonic imaging | Yes (linear probe) |
Color Mode:
| Gain | 0~100 |
| Color Maps | 1~12 |
| Doppler Steer Angles | 7 Steps |
| Wall Filter | 1~4 |
| Persistence/Frame Average | 1~5 |
PW Mode:
| Gain | -20~20 |
| D Linear Velocity | L/M/H |
| Doppler Steer Angles | 5 Steps |
| Wall Filtering | 1~3 |
| Correction Angle | 80°/-80° |
| Max PRF | 10kHz |
| Baseline Adjustment | -3~3 |
Basic Measurement:
| B-mode | Distance, Perimeter and Area (ellipse or track-based method),
Volume |
| M-mode | Heart Rate, Time, Distance, Speed |
| PW-mode | Heart Rate, Velocity, S/D, PI, RI |
