STATEMED Series LED Film viewer (LED film viewer), adopting contemporary advanced LED solid-state light source and backlight source technology, is the new generation observation device for medical imaging films. As for the viewing screen, not only its brightness but also the uniformity and stability of brightness are high, without any dark spaces and flickers. The light source is characterized by rapid light-emitting, little color temperature attenuation and non- mercury. Therefore, the LED film viewer is of great value that can greatly enhanced the quality of observation device for medical imaging films and ensure the diagnostic quality of medical imaging.

Working principles:

1. Main parts of equipment: LED light source, light guide plate, reflecting film, viewing screen, switching mode power supply, and film clip.

2. The power supply of LED light source can be got though converting AC220V to DC24V by switching mode power supply.

3. After refracting by light guide plate and reflecting by reflecting film many times, the strong light with high color temperature emitting from the LED light source, enables the uniform, soft and white light appear on the viewing screen for film observation.

4. The film clip ensures that films can be conveniently and firmly inserted on the viewing screen, also be removed easily.

Use purpose

Used for observing medical imaging films.

Normal operating conditions

a) Environmental temperature: +5℃～+35℃;

b) Relative humidity: Not more than 75%;

c) Atmospheric pressure: 75KPa～106KPa;

d) Input voltage: AC220V±10%, Frequency: 50/60Hz;

e) The equipment should be well earthed and the earth resistance should be not more than 0.1Ω.

Environmental conditions of storage and transportation

a) Environmental temperature: －40℃～＋55℃;

b) Relative humidity: Not more than 93%;

c) Atmospheric pressure: 50KPa～106KPa;

e) Ventilated room without corrosive gas, and dust.

Specification:
