4.7 Kg Vet Use Laptop Black / White Ultrasound Scanner With Strong Aluminum Box

Application:

Abdominal, urology, obstetrics and gynecology, pediatrics / neonatology, superficial structure / small organs, musculoskeletal, heart and so on.

Product Configuration:

Main unit , power adapter PH80, 3 × 0.75MM power cord

12.1 inch medical LED display, 10400mA lithium battery

Net weight: 4.7KG

Gross Weight: 9.5KG

Manual

Warranty Card

Certificate

Packaging plastic bags

Desiccant

Paper box

3.5MHz 80-element convex probe (optional)

5.0MHz 80-element micro-convex probe (optional)

7.5MHz 80-element high-frequency linear array probe (optional)

6.5MHz 80-element rectal probe (optional)

7.5MHz 80-element back fat probe (optional)

Frequency range: 3.5MHz: 2.0MHz, 2.5MHz, 3.5MHz, 4.0MHz, 5.0MHz

5.0 MHz, 4.0 MHz, 4.5 MHz, 5.0 MHz, 6.5 MHz, 7.0 MHz

6.5 MHz: 5.0 MHz, 5.5 MHz, 6.5 MHz, 7.5 MHz, 8.5 MHz

7.5 MHz: 5.5 MHz, 6.5 MHz, 7.0 MHz, 7.5 MHz, 9.0 MHz

Specifications

Main unit system:

Digital beamforming

Real-time dynamic aperture imaging

real-time dynamic sound velocity trace

real-time dynamic launch point by point focus

Real-time dynamic reception point-by-point focusing

8-segment digital TGC

Tissue harmonic imaging unit

Dynamic digital filtering

image enhancement, row correlation, frame correlation, point correlation, linear interpolation and other image processing technology

probe interface:

Function Introduction

1. Display mode: B, B + B, 4B, B + M, M.

2. measurement, distance, circumference, area, volume, heart rate, pregnancy week (BP, GS, CRL, HC, AC, EDD, AFI) and the expected date of birth, fetal weight display, etc.,

3. electronic focus: four electronic focus

4. body mark: ≥ 90 kinds

5. Image mirroring: up and down, left and right, black and white , in any mode can be changed and operated.

6. images can be 0 °, 90 °, 180 °, 270 °, 360 ° rotation

7. through the trackball cursor to select the function package and measurement methods

8. Character display: date, time, name, sex, age, doctor, hospital, comment (full screen character editing) (can be mixed with letters, numbers, punctuation, arrows)

9. cine loop: ≥ 512 frames, can be continuous to play or view by line.

10. permanent storage: built-in 8G memory, ≥ 4000 images, support U disk storage (can be read)

11. puncture guidance function;

12. 0-3 , four kinds of frame correlation, with independent keys, can be adjustable, can be adjusted, you can also change by trackball cursor;

13. 6 kinds of line correlation, with independent buttons, can be adjustable, recycled visual adjustment, you can also change the trackball cursor.

14. 0-7 , 8 kinds of gamma correction, with independent buttons, can be adjustable, recycled visual adjustment, you can also change the trackball cursor.

15. edge enhancement, 0-3, 4 kinds of adjustment, with independent keys, can be adjustable visually, can be adjusted cyclically, you can also change by trackball cursor;

16. scanning range, 0-3, 4 kinds, with independent keys, adjustable, can be adjusted cyclically, you can also change by the trackball cursor;

17. Interface: RS-232 , VGA , VIDEO , 2 USB ports, DICOM

2D image

gray scale: 256 level

Grayscale: 7 kinds, can be adjustable

Dynamic range: 0-135dB

Resolution: horizontal ≤ 2mm; longitudinal ≤ 1mm

Focus points: 1-4 focus optional, adjustable focus position continuously

STC Gain Adjustment: 8 segments

Tissue Harmonics: 0-1MHZ

Maximum scan depth: 3.5mhz ≥ 307mm Visual adjustable

5.0MHz: 62-180mm

6.5MHz: 62-139mm

7.5MHz: 35-104mm

Zoom function: Overall zoom

Image level adjustment: 0-1

black and white flip: 0-1

depth adjustment: 16 level

Gain: 0 ~ 100 adjustable.

scanning speed: 0-7

M pseudo color: 0-7

Blind zone: ≤ 4

Geometric accuracy: horizontal ≤ 5%, vertical ≤ 5%

Resolution: lateral ≤ 2mm, axial ≤ 1mm

Applications:

Cow, horse, sheep, swine, cat, dog.

Inspection in the process of embryo transfer.

Recognition of false pregnancy of pig, horse etc.

Diagnosis of diseases on reproductive systems like uterus, ovaries.

Diagnosis of pregnancy, fetal development, fetal vitality and gender identification.

Diagnosis of all kinds of animal mammary tumor, abscess, hematoma.
