    128 E Diagnostic Baby Color Doppler Ultrasound Scanner B / M Display Mode Customized

    Ask Lasest Price
    Brand Name : STATEMED
    Model Number : STT2-CDU32
    Certification : CE
    Price : competitive
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100 sets per month
    Delivery Time : 10 working days
    • Product Details
    • Company Profile

    128 E Diagnostic Baby Color Doppler Ultrasound Scanner B / M Display Mode Customized

    128 E Diagnostic Baby Color Doppler Ultrasound Scanner B / M Display Mode Customized


    Performance requirements in grayscale imaging mode


    Color ultrasound in the gray scale imaging mode of the performance of the probe:


    PerformanceProbe type and nominal frequency
    2.0≤f<5.05.0≤f<8.05.0≤f<10.0
    a) Robe type, modelConvex array (model TC60A)Cavity (model TC10A)Line array (model TL40A)
    b) Robe nominal frequency (MHz)3.55.57.5
    c)Robe depth(mm)≥160≥80≥50
    d) Lateral resolution (mm)

    ≤3(depth≤80)

    ≤4(80<depth≤130)

    ≤2(depth≤40)≤2(depth≤40)
    e) Axial resolution (mm)

    ≤2(depth≤80)

    ≤3(80<depth≤130)

    ≤1(depth≤40)≤1(depth≤50)
    f) Blind zone (mm)≤5≤5≤3
    g) Horizontal geometric position accuracy (%)≤15≤20≤10
    h) Longitudinal geometric position accuracy (%)≤10≤10≤5
    i) Slice thickness (mm)≤7≤5≤5
    j) Perimeter and area measurement deviations (%)≤±20≤±20≤±20
    k) M mode time display error (%)≤±10≤±10≤±10


    Transport:
