Portable veterinary equipment for cattl, cow,horse,sheep,dog,cat

Wide application: abdomen, OB/GYN, urology, cardiology, small parts etc;
USB Function of image store: more than Sixteen thousand images;
Power supply: AC 110V-240V, 50HZ/60HZ;
Probe connector: 2;
USB/VGA/ ports;
Video connector;

Main Technical Specification:
Scanning mode: Convex/Linear/Trans-vaginal/Trans-rectal;
Display modes: B, B+B, B+M, M, 4B;
Scanning depth: 240mm;
Gray scales: 256;
Body marks: 33;
Function of image magnification: image zoom (real-time status under B mode), up to 5 times (area); local amplification function which can be enlarged under the real-time and froze;
Image conversion: up/down, left/right, black/white;
Function of puncture guide;
Max dynamic range>=100db;
Detecting depth>=190mm, scanning depth>=240mm;
Software reset function;
Printer function: can connect laser printer and Video printer directly;
Zooming: *1.0, *1.2, *1.5, *2.0;
Port: USB 2.0, VGA, Video connector;

Measurement:
General menu: Distance, Area, Volume, Angle, Ellipse;
Obstetrics menu: GS, CRL, BPD, HC, AC, FL, Fetus Weight;
Heart menu: Distance, Time, Slope, Rhythm;

Standard configuration:
12 inches LCD main unit;
2.5-7.5MHZ Convex array probe;
two probe sockets;
USB,VGA,video,printer ports;

Options:
Linear array probe;
Micro-Convex array probe;
Trans-vaginal array probe;
Trans-rectal probe;
Mitisubishi Video Printer;

Inside battery

State (Beijing) Medical Technology Co., Ltd. established in 2002, is a High-tech medical products enterprise combining R&D, production ,sales and after-sale together, specialized in Medical Ultrasonic Instruments, ENT Workstation, Medical Endoscope Imaging Systems, Colposcope, Spectral Instrument for gynecology, Plasma Air Disinfection Machine, X-ray machines and etc. We constantly develop high-quality electric medical devices by adopting the domestic advanced technical facilities to blend the computer information process technology and clinical medicine research perfectly.

With advanced ultrasonic technology, high-standard quality system, strict production process control and efficient after-sales service, our medical ultrasound products has obtained the trust of many medical institutions, such as Colour Doppler ,Digital B/W Ultrasound, Wireless Mini Ultrasound Scanner. Our Colour Doppler is the advanced scientific research achievement of State, which is the reflection that State has been taking customer's demand as design concept and making excellent technology innovation as backup force whether from scalable structure or high-quality images and powerful clinical application. State supply cost-effective and best image colour ultrasounds to global medical communities and make ultrasonic diagnosis enter into a new level. State has got good social and economic benefits because it pays attention to develop new technology and products, train and introduce high-quality talents.

State has first passed the ISO 13485 certificate and the Quality System Certification of ISO9001 as early as 2004 among the same industry in China. The ISO14001 environmental management system certification and ISO 18001 occupational health and safety management system certification has been obtained in 2012. By the end of 2016, three products of our factory have passed the European CE certification. So far, we have 4 computer software copyrights, 2 invention patents, 18 practical and new patents. We always put "quality-oriented, customer the first" as our tenet and stick to the belief "high-standard product, excellent service". We will explore and develop unceasingly and try to make outstanding contributions to human health in the world, which is the common goal of every State people.
