Human Clinic Full Digital Diagnostic Ultrasound Equipment Portable
Ultrasound Scanner
Company Introduction:
State (Beijing) Medical Technology Co., Ltd. established in 2002,
is a High-tech medical products enterprise combining R&D,
production ,sales and after-sale together, specialized in Medical
Ultrasonic Instruments, ENT Workstation, Medical Endoscope Imaging
Systems, Colposcope, Spectral Instrument for gynecology, Plasma Air
Disinfection Machine, X-ray Machines, Enteral Feeding Pump, Red
Light Therapy Instrument and etc. We constantly develop
high-quality electric medical devices by adopting the domestic
advanced technical facilities to blend the computer information
process technology and clinical medicine research perfectly.
State has first passed the ISO 13485 certificate and the Quality
System Certification of ISO9001 as early as 2004 among the same
industry in China. The ISO14001 environmental management system
certification and ISO 18001 occupational health and safety
management system certification has been obtained in 2012. By the
end of 2016, three products of our factory have passed the European
CE certification. So far, we have 4 computer software copyrights, 2
invention patents, 18 practical and new patents. We always put
"quality-oriented, customer the first" as our tenet and stick to
the belief "high-standard product, excellent service". We will
explore and develop unceasingly and try to make outstanding
contributions to human health in the world, which is the common
goal of every State people.
Main Features:
Powerful measurement & calculation software packages
8-Segment TGC ABD Trackball adjustment
10 inch CRT monitor
OB measurements: BPD, GS, CRL, FL, AC, HC, etc
Permanent function of image store: 32 images
Back-lit keyboard
2 probe connectors
Probe automatic identification
Main Technical Specification:
Scanning mode: Convex/Linear/Trans-vaginal/Trans-rectal;
Display modes: B, B+B, B+M, M, 4B;
Scanning depth: 240mm;
Gray scales: 256;
Body marks: 33;
Function of image magnification: image zoom (real-time status under
B mode), up to 5 times (area); local amplification function which
can be enlarged under the real-time and froze;
Image conversion: up/down, left/right, black/white;
Function of puncture guide;
Max dynamic range>=100db;
Detecting depth>=190mm, scanning depth>=240mm;
The geometric location accuracy: vertical<=5%; lateral<=5%;
blind spot: <=4mm;
Vertical resolution: <=1mm (depth<=130mm) < =2mm (130mm
Lateral resolution: <=1mm (depth<=130mm) < =2mm (130mm
Gamma: 4 gray scale γ transform function;
Variety of focus selection and multi-stage dynamic focusing with 4
transmit focus; support to launch multi-focus combination;
Built-in pseudo color processor, Pal-D and VGA video output, can
connect external screen monitors, color monitors, VCRs, video image
printer and other equipment.
Fixed characters and real-time clock and calendar display;
Software reset function;
Printer function: can connect laser printer and Video printer
directly;
Comment: Date, Name, Sex, Age, Hospital, Annotation;
Zooming: *1.0, *1.2, *1.5, *2.0;
Port: USB 2.0, VGA, Video connector;
Wide application: abdomen, OB/GYN, urology, cardiology, small parts etc;
USB Function of image store: more than Sixteen thousand images;
Power supply: AC 110V-240V, 50HZ/60HZ;
Probe connector: 2;
USB/VGA/ ports;
Video connector;
Measurement:
General menu: Distance, Area, Volume, Angle, Ellipse;
Obstetrics menu: GS, CRL, BPD, HC, AC, FL, Fetus Weight;
Heart menu: Distance, Time, Slope, Rhythm;
Standard configuration:
10 inches CRT main unit;
2.5-7.5MHZ Convex array probe;
two probe sockets;
USB,VGA,video,printer ports;
Options:
Linear array probe;
Micro-Convex array probe;
Trans-vaginal array probe;
Trans-rectal probe;
Mitisubishi Video Printer;
