6.6KG All-Metal Structure Medical Double panel LED X Ray Film Viewer

Technical parameters

• Specification: 1504*488*21
• Observation screen: 1424*425
• Installation pitch: 1469
• Luminance(cd/㎡): 4000/6000
• Brightness dimmer: 10-100%
• Power supply: AC100~240V 50~60Hz
• Net Weight: 12Kg

Functions

1. Subzone-inductive control and light dimmer type
2. Normal type(fixed brightness)
3. Inductive control and light dimmer type(bright once open and light dimmer)
4. Inductive control type(bright once open)

Characteristics

1. Aluminum alloy frame:;decease light decay and color decay; sturdy and durable
2. Ultra-thin, the whole structure thickness is only 21mm
3. High brightness, max rated brightness over 4000cd/㎡, suitable for observing films of different density
4. Clipping instruction; self locking of roller pin and ball bearing
5. Light source: 5630 SMD LED from Germany OSRAM special for chip backlight is used, light efficiency over 100lm/w and use life up to one hundred thousand hours
6. Color temperature: 6500±K500; true white light without dazzling and protect doctor’s eyes
7. Light guide plate is edge-lit backlight; more uniform brightness distribution and uniform degree more than 90%; little light loss
8. Uniform brightness distribution without flickers, dark spaces, and eye strain
9. Control brightness through digital control key, it will shut down automatically with buzzer if no actions in 5 minutes; 0~9 stepless dimming; brightness memory
10. The screen size is same as film, which avoid light interference, even 14*17 film without light leakage
11. LED light bar is welded by automatic chip mounter without lead reflux, which avoid cold solder joint and LED damage because of high temperature during manual welding, and ensure product quality
12. Without mercury, energy-conserving and environment-protective; no temperature difference effect, and can be lighted up one open even if in low temperature.
