Ultra-thin Four panel Quadruplicate Aluminum Alloy Frame LED Medical X Ray Film Viewer

Performances

1. PWM digital dimming adjustable
2. Inserted chip controlled
3. Power supply optional

Technical parameters

Characteristics

1. Light source: 5630 SMD LED from Germany OSRAM special for chip backlight is used, light efficiency over 100lm/w and use life up to one hundred thousand hours
2. Color temperature: 6500±K500; true white light without dazzling and protect doctor’s eyes
3. Aluminum alloy frame:;decease light decay and color decay; sturdy and durable
4. Ultra-thin, the whole structure thickness is only 21mm
5. High brightness, max rated brightness over 4000cd/㎡, suitable for observing films of different density
6. Innovative film inserting; film inserts precisely; sturdy and durabl
7. Clipping instruction; self locking of roller pin and ball bearing
8. Light guide plate is edge-lit backlight; more uniform brightness distribution and uniform degree more than 90%; little light loss
9. Uniform brightness distribution without flickers, dark spaces, and eye strain
10. The screen size is same as film, which avoid light interference, even 14*17 film without light leakage
11. Without mercury, energy-conserving and environment-protective; no temperature difference effect, and can be lighted up one open even if in low temperature
12. LED light bar is welded by automatic chip mounter without lead reflux, which avoid cold solder joint and LED damage because of high temperature during manual welding, and ensure product quality
13. Control brightness through digital control key, it will shut down automatically with buzzer if no actions in 5 minutes; 0~9 stepless dimming; brightness memory

State (Beijing) Medical Technology Co., Ltd. established in 2002, is a High-tech medical products enterprise combining R&D, production ,sales and after-sale together, specialized in Medical Ultrasonic Instruments, ENT Workstation, Medical Endoscope Imaging Systems, Colposcope, Spectral Instrument for gynecology, Plasma Air Disinfection Machine, X-ray machines and etc. We constantly develop high-quality electric medical devices by adopting the domestic advanced technical facilities to blend the computer information process technology and clinical medicine research perfectly.

With advanced ultrasonic technology, high-standard quality system, strict production process control and efficient after-sales service, our medical ultrasound products has obtained the trust of many medical institutions, such as Colour Doppler ,Digital B/W Ultrasound, Wireless Mini Ultrasound Scanner. Our Colour Doppler is the advanced scientific research achievement of State, which is the reflection that State has been taking customer's demand as design concept and making excellent technology innovation as backup force whether from scalable structure or high-quality images and powerful clinical application. State supply cost-effective and best image colour ultrasounds to global medical communities and make ultrasonic diagnosis enter into a new level. State has got good social and economic benefits because it pays attention to develop new technology and products, train and introduce high-quality talents.

State has first passed the ISO 13485 certificate and the Quality System Certification of ISO9001 as early as 2004 among the same industry in China. The ISO14001 environmental management system certification and ISO 18001 occupational health and safety management system certification has been obtained in 2012. By the end of 2016, three products of our factory have passed the European CE certification. So far, we have 4 computer software copyrights, 2 invention patents, 18 practical and new patents. We always put "quality-oriented, customer the first" as our tenet and stick to the belief "high-standard product, excellent service". We will explore and develop unceasingly and try to make outstanding contributions to human health in the world, which is the common goal of every State people.
